Product Summary
The SFH551 is a transimpedance amplifier with digital TTL open collector output stage and integrated photodiode. The active area of the SFH551 in connection with the molded microlens gives an efficient coupling from the end of a plastic fiber. The SFH551 is fully DC coupled and therefore no line code is needed. The applications of the SFH551 include Household electronics, Power electronics, Optical networks.
Parametrics
SFH551 absolute maximum ratings: (1)Operating Temperature Range: -40 to +85鈩? (2)Storage Temperature Range: -40 to +100鈩? (3)Soldering Temperature(2mm from case bottom, t 鈮?5 s): 260鈩? (4)Supply Voltage Range without Damage: -0.5 to 15 V; (5)Recommended and Guaranteed Maximum Voltage: 5.5 V; (6)Minimum Supply Voltage for Function: 4 V; (7)Minimum Pull-up Resistance(VCC = 5 V): 330 惟; (8)Output Voltage: 鈥?.5 to 15 V; (9)Output Current: 50 mA; (10)Power Dissipation (output): 100 mW.
Features
SFH551 features: (1)Bipolar IC with open-collector output; (2)Digital output, TTL compatible; (3)Sensitive in visible and near IR range; (4)Low switching threshold; (5)Transfer rate 鈮?5 Mbit/s; (6)2.2 mm aperture holds standard 1000 micron plastic fiber; (7)No fiber stripping required; (8)Molded microlens for efficient coupling.
Diagrams
<IMG border=0 src="http://www.seekic.com/uploadfile/ic-mfg/201252232821516.jpg">
