Product Summary
The SFH756 is a Plastic Fiber Optic Transmitter Diode. The applications of the SFH756 include Household Electronics, Power Electronics, Optical Networks, Light Barriers.
Parametrics
SFH756 absolute maximum ratings: (1)Operating Temperature Range: 鈥?0 to +85 鈩? (2)Storage Temperature Range: 鈥?0 to +100 鈩? (3)Junction Temperature: 100 鈩? (4)Soldering Temperature (2 mm from case bottom, t 鈮?5 s): 260 鈩? (5)Reverse Voltage: 3 V; (6)Forward Current: 50 mA; (7)Surge Current (t 鈮?10 渭s, D = 0): 1 A; (8)Power Dissipation: 120 mW; (9)Thermal Resistance, Junction/Air: 450 K/W.
Features
SFH756 features: (1)2.2 mm Aperture holds Standard 1000 Micron Plastic Fiber; (2)No Fiber Stripping Required; (3)Good Linearity (Forward current > 2 mA); (4)Molded Microlens for Efficient Coupling.
Diagrams
<IMG border=0 src="http://www.seekic.com/uploadfile/ic-mfg/201252232842217.jpg">
